The new state-of-the-art campus of the National Academy of Customs, Indirect Taxes, and Narcotics (NACIN) was conceptualized and built. Spread across 500 acres, the academy is the apex institution of the Government of India for capacity building in the field of Indirect Taxation (Customs, Central Excise, and Goods and Services Tax) and Narcotics Control Administration. This national-level, world-class training institute will impart training to the officials of the Indian Revenue Service (Custom & Indirect Taxes), as well as to the central allied services, state governments, and partner nations. NACIN will be the national-level, world-class training institute for IRS officers and officer trainees of the Royal Civil Service of Bhutan.
The Prime Minister, Mr. Narendra Modi, inaugurated the new campus on 16 January 2024. He expressed confidence that the new campus of NACIN will create new dimensions of good governance and give a boost to trade and industry in the nation.
State-of-the-Art Government Facility of NACIN on DERWISER Solutions:
High-end training/education institutes are critical environments where users expect, all internal IT infrastructure to be nonhazardous and environmentally friendly, with high-end real-time performance. Considering this as an Institute of National Importance, where global collaboration is expected, the infrastructure should also be up to date with the latest cutting-edge, robust, high-performance solutions. The proposed cables and wires, which were supposed to be routed through shafts, ducts, etc., should be of high-grade fire resistance, zero halogen, and provide a smoke-free environment so that in the event of any unforeseen incident, the cables should not facilitate the spread of fire.
Our Solutions:
Derwiser’s expert team understood the customer requirements through RFP as planned, designed, and validated by concerned authorities. We provided 100% compliant solutions of LAN cables with accessories for data, voice, video, and CCTV applications through our high-quality and best-in-class products from Derwiser’s structured cabling solutions.
Solution offering comprises of:
- Cat6A Cable and accessories confirming to 10 Gigabyte throughput.
- Cat6A Jack (I/O), Patch Panel, Patch cord confirming to 10G.
- Toolless I/O with specially hinged strain relief and bend-limiting boot for extra protection of bend limit for better performance.
- Transparent shutter patch panel to provide a dust-free environment at I/O mating points.
- Backbone fiber optic cables and connectivity for seamless data flow.
We introduced advance Cat6A U/UTP cables & copper patch cord, compliant with IEC 60332-3-22 standards. This not only ensured high-speed data transfer but also enhanced safety with fire-resistant connectivity.
Derwiser Fiber Optic SM OS2 G.657 A2 Bend Insensitive standards with ultra-low loss cables & accessories for unlimited bandwidth. To ensure complete safety, Derwiser Fiber optic cables supplied are of FRLSZH sheathing & Dry core construction. The Fiberoptic patch cord and pigtails also have LSZH sheathing. Derwiser also confirms to supply its Indoor wall mount rack and floor-standing racks of various sizes and dimensions for this project.
Product Supplied and Impact:
Cat6A Cable: DWC-6AU4C305BD
- Ensures transmission and safety across a campus of over 5000 nodes.
- Lab-tested by NBL and accredited for fire resistance per IRC 60332-3-22 standard (for a bunch of cables), promoting the safety of cables and humans.
- Transmission parameters surpass latest standards, ensuring end-to-end channel performance of 10 G across the NACIN campus network.
Toolless I/O: DWC-IO6AUPXXA
- Exceeds the latest transmission parameter standards, allowing cable termination on this connecting hardware with minimal loss.
- Toolless feature facilitated faster termination of approximately 10000+ terminations, on both patch panel and face plate side.
- Double-locking mechanism ensures a robust and future-proof I/O assembly, preventing loose connections and maintenance rework.
Patch Panel: DWC-PPXXU241
- Unique in the industry for its transparent shuttle or panel. Not only aesthetically pleasing, it also protects connectors from dust and ingress particles.
- Clear label holders enable proper port numbering for future alterations at NACIN Campus.
- Documentation as per standard is crucial for such a high node density campus.
Field termination plug: DWC- PG6ASTSGI
- The IP 20 rated Field Termination Plug or Direct Attach plug is used at NACIN Campus.
- Enables direct connection with any outdoor active devices, eliminating the need for outdoor enclosures or other space-consuming solutions.
- Cables terminated on this plug at NACIN Campus are included in the site performance warranty.
Fiber optic cable: DWF CODAOS2USL- 06 and DWF- COAOS2MSH-12
- Single-mode cable data transmission parameters enable the campus backbone to operate at 1G and 10G backplane speeds over long distances.
- Bending Insensitive property of fiber cores facilitates smooth installation across the NACIN campus.
- FRLSZH outer sheath, dry core, and ultra-low loss properties ensure safety and performance in accordance with the latest standards.
Fiber LIU: DWF-LOS2DLLCS-24
- Comes fully loaded with adapter and LCZH pigtails from day one, aiding in systematic and loss-free splicing and terminations of fiber cables.
- Sliding feature of LIU facilitates easy operations during maintenance work or changes in fiber connectivity.
- Standard rack-mounted robust metal assembly with powder coating enhances product lifespan and reduces wear and tear.
Fiber patch cords: DWF-POS2DLCLCPL-3
- When grouped inside rack dressing, if fiber patch cords catch fire, it could spread inside the main core rooms of the campus.
- LSZH outer sheath provides fire-resistant installations inside racks.
Impact & Results:
- Derwiser and its partner could understand the criticality and urgency of materials, and the Operation Team, worked time-bound mission along with production to fasten the entire process for smooth delivery.
- As per requirements, most of the systems have to be tested from various independent NABL & iLAC-MRA approved LAB, which confirms the desired specification gets delivered.
- With 100 % indoor cabling solutions like CAT6A cable and components and fiber optic cabling solutions, are LSZH in accordance to global standards like IEC 60332-1, IEC 60332-3-22, IEC 61034-2, IEC 60754-1 /2 along with RoHS compliant products makes the Derwiser deliverables are safe, non-hazardous.
- Because of end-to-end 10G ready solutions, it guarantees the best performance at high-speed transmission in this state-of-the-art assembled premises.
